Atlas Packing

For fast loading of z-stacks to the GPU, FPBioimage uses texture atlases. To save download time, these texture atlases can be provided directly to FPBioimage.

To support volumetric images of up to 512x512x512, FPBioimage uses 8 texture atlases, each with a maximum size of 4096x4096. The location of each image slice on the texture atlas array is determined by a custom procedure, shown below in java and python.

Note that oversized image stacks must first be cropped or scaled to a maximum size of 512x512x512.

Java

int sliceWidth = volumeImage.width;
int sliceHeight = volumeImage.height;
int numSlices = volumeImage.depth; // Number of z-slices

int numberOfAtlases = 8; // Fixed for FPBioimage version 4

// Round image size up to next power of 2
int paddedSliceWidth = ceil2(sliceWidth);
int paddedSliceHeight = ceil2(sliceHeight);

int xOffset = (int)Math.floor((paddedSliceWidth - sliceWidth)/2);
int yOffset = (int)Math.floor((paddedSliceHeight - sliceHeight)/2);

// Calculate the xy size of the atlases, making atlases as square as possible
int slicesPerAtlas = (int)Math.ceil((float)numSlices/(float)numberOfAtlases);
int atlasWidth = ceil2(paddedSliceWidth); // ceil2() rounds up to next power of 2.
int atlasHeight = ceil2(paddedSliceHeight * slicesPerAtlas);
while ((atlasHeight > 2*atlasWidth) && (atlasHeight > sliceHeight)) {
	atlasHeight /= 2;
	atlasWidth *= 2;
}

// Initialise an array of 8 black 2D textures to become atlases
Image[] atlasArray = new Image[numberOfAtlases];
for (int i=0; i<numberOfAtlases; i++){
	atlasArray[i] = new Image(atlasWidth, atlasHeight, black);
}

// Fill out atlases with image slices
int slicesPerRow = (int)Math.floor((float)atlasWidth/(float)paddedSliceWidth);
for (int i=0; i<numSlices; i++){
	int atlasNumber = (int)((float)i % (float)numberOfAtlases);
	int locationIndex = (int)Math.floor((float)i/(float)numberOfAtlases);

	// Get slice
	Image slice = volumeImage.getSlice(i);

	// Put slice into atlas at the correct position
	int xStartPixel = (int)((float)locationIndex % (float)slicesPerRow) * paddedSliceWidth + xOffset;
	int yStartPixel = (int)Math.floor((float)locationIndex / (float)slicesPerRow) * paddedSliceHeight;

	// The following line should be uncommented for coordinate systems that start top-left
	//yStartPixel = atlasHeight - yStartPixel - paddedSliceHeight + yOffset;

	copySubImageToAtlas(sliceTexture, atlasArray[atlasNumber], xStartPixel, yStartPixel);
}

Python

The following code makes a set of texture atlases out of a 170x320x30 volume image.

import math
import matplotlib.pyplot as plt
import numpy as np
from scipy import misc
from scipy import ndimage

def ceil2(x):
    # Round up to the next power of 2
    return 1<<(x-1).bit_length()

# In this example, image slices will be loaded from a folder
filepath = 'C:\\Users\\user\\Pictures\\example\\'
filenameprefix = 'example'

# Get/set volume image details
sliceWidth = 170
sliceHeight = 320
numSlices = 30

numberOfAtlases = 8 # Set for FPBioimage v4

# Calculate necessary variables
paddedSliceWidth = ceil2(sliceWidth)
paddedSliceHeight = ceil2(sliceHeight)

xOffset = math.floor((paddedSliceWidth-sliceWidth)/2)
yOffset = math.floor((paddedSliceHeight-sliceHeight)/2)

slicesPerAtlas = math.ceil(numSlices/numberOfAtlases)
atlasWidth = ceil2(paddedSliceWidth)
atlasHeight = ceil2(paddedSliceHeight * slicesPerAtlas)
while (atlasHeight > 2*atlasWidth) & (atlasHeight > sliceHeight):
    atlasHeight /= 2
    atlasWidth *= 2
atlasHeight = int(atlasHeight) # Cast back to int after division

# Create RGBA (4-channel) atlas array:
atlasArray = np.zeros((atlasHeight, atlasWidth, 4, numberOfAtlases), dtype=np.int32)

# Arrange slices into atlas
slicesPerRow = math.floor(atlasWidth/paddedSliceWidth)
for i in range(0, numSlices):
    atlasNumber = i % numberOfAtlases
    locationIndex = math.floor(i/numberOfAtlases)

    # Load from a file, in this example
    file = filepath + filenameprefix + str(i).zfill(4) + '.png'
    imslice = misc.imread(file, mode='RGBA')

    xStartPixel = (locationIndex % slicesPerRow) * paddedSliceWidth + xOffset
    yStartPixel = math.floor(locationIndex / slicesPerRow) * paddedSliceHeight + yOffset

    # Python coordinate system starts top-left:
    yStartPixel = atlasHeight - yStartPixel - paddedSliceHeight + 2*yOffset

    atlasArray[yStartPixel:yStartPixel+sliceHeight, xStartPixel:xStartPixel+sliceWidth, :, atlasNumber] = imslice

# Save the atlases
for a in range(0, numberOfAtlases):
    misc.imsave('atlas' + str(a) + '.png', atlasArray[:,:,:,a])

This python code results in the follow array of atlases:

Note that the pixels surrounding the image slices have values of (0,0,0,0), i.e. black and fully transparent. Click on them for a clearer view.
